Description:
It is made from graphite as homogeneous, reinforced by metal mesh, foil or tanged metal. It offers excellent sealing capabilities such as thermal stability, self-lubrication, corrosion resistance, without being brittle and aging etc., under extreme conditions with a longer life and less maintenance.

Gasket Style	ZR-200T	ZR-200TP	ZR-200TT	ZR-200TM
Without eyelet	ZR-200T	ZR-200TP	ZR-200TT	ZR-200TM
With inner eyelet	ZR-200TIR	ZR-200TP IR	ZR-200TT IR	ZR-200TM IR
With outer eyelet	ZR-200T CR	ZR-200TP CR	ZR-200TT CR	ZR-200TM CR
With I & O eyelets	ZR-200TIC	ZR-200TP IC	ZR-200TT IC	ZR-200TM IC
Insert material	None	SS304、316 etc	SS304、316、CS	CS、304/316
		Foil	Tanged	Mesh
		0.05mm	0.1mm,0.25mm-CS	0.1mm

APPLICATION & PROPERTIES:
Various shapes are available, used in petrochemical, mining, vessels, boilers, piping and duct,pumps and valves, flanges etc. Suitable for steam, mineral oils, heat transfer oils, hydraulic oil,fuel, water, seawater, freshwater etc.

Sheet Style	ZR-200T	ZR-200TP	ZR-200TT	ZR-200TM
Compressibility	30%	15~35%	15~35%	15~35%
Recovery	≥10%	≥20%	≥20%	≥20%
Pressure	40bar	200bar	300bar	200bar
Density g/cm3	0.7; 1.0	1.0	1.0	1.0
Temperature0C	-240~550	-240~550	-240~550	-240~550
PH	0~14	0~14	0~14	0~14

Graphite properties:
　

Item	Tolerance of density	C≥%	Tensile strength	Sulphur content	Chlorine content	Stress relaxation	Ignition loss
Industrial	±0.06 g/cm3	98	4 Mpa	<1000ppm	<50ppm	10%	2.0≤%
Nuclear	±0.05 g/cm3	99.5	5 Mpa	<700ppm	<35ppm	10%	0.5≤%

　

SINSTON ZR-200T Pure Graphite Gasket

SINSTON ZR-200TP Foil metal reinforced Graphite Gasket

SINSTON ZR-200TT Tanged metal reinforced Graphite Gasket

SINSTON ZR-200TM Mesh reinforced Graphite Gasket
